| Model |
: |
|
V2500E-1 V3500E-1 |
| Plot length |
: |
|
2200mm (86”) 3200mm (126”) |
| Screen size |
: |
|
2500mm (98”) 3500mm (137”) |
| Speed |
: |
|
1 to 5 min per-screen, depending on print resolution |
| Print method |
: |
|
Step Print (high quality), Layer Print (smooth tone), Spiral Print (high speed) |
| Room temperature |
: |
|
20°C to 25°C |
| Humidity |
: |
|
65% – 75% |
| Print head |
: |
|
New Ultrajet 1440 nozzle print dead |
| Print resolution |
: |
|
360 x 360dpi, 360 x 720dpi, 720 x 720dpi & 1440 x 720dpi |
| Compressed air |
: |
|
Minimum 4.00 bar |
| Circumference / repeat |
: |
|
640, 820, 914 & 1018mm, optional 720mm |
| Head adjustment |
: |
|
Auto head adjust to circumference diameter |
| Exposing unit |
: |
|
Online UV exposing unit |
| Cleaning station |
: |
|
Automatic head cleaning system with wiper |
| Ink supply system |
: |
|
Auto-pumping & filter system, sub-tank & gravity damper |
| Interface |
: |
|
USB 2.0 data card |
| Control panel |
: |
|
Touch panel |
| Electrical power |
: |
|
240V AC +/- 10% |
| Structure |
: |
|
Robust design |
| Electronic |
: |
|
Multilayer motherboard, USB 2.0 data & daughter card, Ultrajet print head-board & differential board |
| Compartment |
: |
|
Ink compartment, electrical & air valve, electronic control compartment |
| X drive |
: |
|
Close loop AC servo motor |
| Y drive |
: |
|
Close loop AC servo motor / DC motor |
| Repeat |
: |
|
Auto-repeat close (circumference – X) according to various repeat, no-Gap & good strip effect with step print |
| Rip |
: |
|
UltraPrint |
| Indicator |
: |
|
Ink supply & waste ink |
